WIRING DIAGRAM
A proper installation of the AeGIS system is very essential. You MUST follow the installation procedures, block diagrams and
installation requirements as specified in this chapter.
2
3
4
5
6
7
1
10
RED
BLACK
WHITE
GREEN
9
2nd relay can be
connected as
Mode 1: Door Control
Mode 2: A Shunt
Mode 3: An Alarm
Mode 4: CCTV switch
Battery
Backup
8
Optional 26 Bit
Wiegand Card
Reader or
Wiegand
Radio Reader
Input. We will
not resposible
for
incompatibility
issue if using
other than
Pach & Co
Proximity
Reader.
