3.
Dedicated phone line, system only can call an outside line; up to 10 tenant directories can be programmed.
Specifications
Input power: 12VAC 40VA (12VAC supplied), 12VDC 3.0A
Minimal Current consumption: 750-100mA
DIMENSION: 6-7/16 (H) x 10 (W) x 2-1/16 (D)
1x16 Liquid Crystal Display (LCD)
Built-in 26 Bit Wiegand Card Reader
RS-485 for Satellite system (up to eight satellite)
Two on-board relays
Two Auxiliary inputs
Operating environment 10ºF-140ºF
Relative Humidity 0%-95% non-condensing
Double 3/4" knock-out on the back and bottom panel
Features
Optional Internet Browser Programming (QWCM)
Event recording
Automatic Enrollment
Automatic call forwarding, intercom mode on existing active phone line
200 total cards or transmitters and 200 access codes (4-8 digit)
20 programmable time zones, 10 programmable auto-unlock schedules and 20 holiday schedules
10 programmable temporary cards and access codes for limited use
10 programmable unlock hold cards and access codes
Program blocks of cards and blocks of codes
Accessories and Replacement parts
Visit our web site
Unpacking the System
All the items below come with the Quantum QR5-QR5FF-QR5IP-QR5IPFF. Contact Pach and Company for missing
part(s) at (888) 678-7224, Monday-Friday 7:30 AM -3:30 PM Pacific Standard Time.
