46-638 Magnetic Liquid Level Indicators
19
2.6.2 Model OES Switch
• Electric snap action switch
• 10 amp DPDT
• ±0.75" (19 mm) float travel
• -58° to +392° F (-50° to +200° C)
• Cast aluminum enclosure, (2)
1
⁄
2
" NPT conduit entries
See bulletin OES for further information
2.6.3 Model ORS Switch
• Electric reed switch, hermetically sealed
• 1 amp SPDT
• Stainless steel enclosure with mounting tabs
• ±0.5" (13 mm) float travel
• -58° to +482° F (-50° to +250° C)
• Stainless steel enclosure with mounting tabs
See bulletin ORS for further information
2.6.4 Model OCT Analog Transmitter
Power:
24 VDC
Maximum Range:
Up to 20 feet standard
(Consult factory for longer lengths)
Accuracy:
±0.5" (13 mm)
Output:
4–20 mA
Temperature range:
-40° to +500° F (-40° to +260°C)
See bulletin OCT for further information
2.6.5 Model 2XX Jupiter
™
Magnetostrictive Transmitter
Power:
24 VDC
Maximum Range:
Up to 35 feet (10.67 meters)
Accuracy:
±0.015" (0.38 mm)
Output:
4–20 mA (HART optional)
Temperature range:
-40° to +175° F (-40° to +79°C)
See bulletin ORI-148 for further information
2.6.6 Model 705 Eclipse Transmitter
See bulletin 57-101 for details
