70
American Dryer Corporation 88 Currant Road / Fall River, MA 02720-4781
Front Base & Front Top Panel Assemblies
Illus. No. Part No. Qty Description
1 * 334542 2 Piston Cover
2 150415 12 Crimptite Sheet Metal Screw
3 * 334671 2 Right Front Base Panel
4 150522 12 1/4-20 x 1/2" TEK Screw
5 332681 2 Right Gusset for Top Front Panel
6 150522 9 1/4-20 x 1/2" TEK Screw
7 * 334546 1 Top Front Panel
8 * 332680 1 Left Gusset for Top Front Panel
9 150522 7 1/4-20 x 1/2" TEK Screw
1 0 150522 9 1/4-20 x 1/2" TEK Screw
* Specify color when ordering
