Steam Coil Assembly
Illus. No.
Part No.
Qty
Description
1
165034
1
Steam Coil Assembly
2
150523
8
1/4-20 x 3/4" Hex Head TEK Screw
3
153007
4
1/4" Lock Washer
4
152002
4
1/4-20 Hex Nut
5
820321
2
Steam Damper Hinge Assembly
6
115995
144
Steam Damper Gasket (sold by the inch)
7
881661
1
Steam Damper Assembly
(includes illus. nos. 6 through 8)
8
102350
2
Steam Damper Foam
9
153007
4
1/4" Lock Washer
1 0
152002
4
1/4-20 Hex Nut
1 1
151008
1
5/8-18 S.S. Acorn Nut
1 2
152030
1
5/8-18 Jam Nut
1 3
100525
1
2" Bore, 4" Stroke Piston
1 4
152002
4
1/4-20 Hex Nut
1 5
153007
4
1/4" Lock Washer
1 6
100526
1
Piston Pivot Bracket
1 7
143238
1
1/8" Brass Close Nipple
1 8
143264
1
1/4" Poly x 1/8" Brass Reducing Bushing
1 9
100496
1
1/8" Needle Valve
2 0
100472
1
1/4" Poly x 1/8" MPT Connector
2 1
143115
--
1/4" O.D. Tubing (sold by the foot)
2 2
143156
1
1/4" Poly Tee
2 3
143115
--
1/4" O.D. Tubing (sold by the foot)
2 4
100472
1
1/4" Poly x 1/8" MPT Connector
2 5
100496
1
1/8" Needle Valve
2 6
143264
1
1/4" Poly x 1/8" Brass Reducing Bushing
2 7
143238
1
1/8" Brass Close Nipple
2 8
100525
1
2" Bore, 4" Stroke Piston
2 9
151008
1
5/8-18 S.S. Acorn Nut
3 0
153030
1
5/8-18 Jam Nut
3 1
152002
4
1/4-20 Hex Nut
3 2
153007
4
1/4" Lock Washer
3 3
100526
1
Piston Pivot Bracket
3 4
152002
2
1/4-20 Hex Nut
3 5
153007
2
1/4" Lock Washer
3 6
153010
2
#6 Star Washer
3 7
152000
2
6-32 Hex Nut
3 8
330987
1
Micro Valve Support
3 9
100472
1
1/4" Poly x 1/8" MPT Connector
4 0
100472
1
1/4" Poly x 1/8" MPT Connector
4 1
143115
--
1/4" O.D. Tubing (sold by the foot)
4 2
100498
1
3-Way Micro Valve - 24 VAC
4 3
150002
2
6/32 x 1" Phillips Head Machine Screw
4 4
100520
1
1/8" N.P.T Silencer
