SB
Drive motor
The drive rolls of the SB wire saw are driven by a hydraulic motor. The drive motor must be in-
stalled before initial commissioning.
Motor attachment
Hydraulic cylinder feed motion
A hydraulic cylinder is used for the feed motion. The feed motion takes place when the dia-
mond wire is pulled into the machine. This is done by swivelling the rocker with the drive rollers
upwards.
3.3
3.3
3.4
3.4
