Diamond Products CC800M - Manual (Page 29)

Gas Block Saw Jackshaft Assembly #6030149
ITEM PART NO. QTY. DESCRIPTION
1 6030139 1 Jack Shaft Guard, Block Saw
2 2900341 4 Cap Screw, Hex Hd., M6-1.0 x 16mm
3 2900009 8 Flat Washer, 1/4" SAE
4 2900024 4 Lock Washer, 1/4" Split
5 2900302 4 Lock Nut, M6-1.0 Nylon Insert
6 6010169 3 Key, 1/4" Sq. x 1-1/4"
7 6030158 1 Jack Shaft, Block Saw #2
8 2900061 2 Grease Fitting, 1/4-28 x 90 Degree
9 2501362 1 Pulley, 2BK32X1"-3.35" Double Groove w/Setscrews
10 2500732 2 Pillow Block Bearing 1"
11 2501193 1 Pulley, 4.25" Single Groove w/Setscrew
12 6030157 2 Jack Shaft Bearing Spacer
13 6030161 1 Plate
14 2501099 2 V-Belt BX44
15 2900014 6 Flat Washer, 3/8" SAE
16 2900006 4 Lock Washer, 3/8" Split
17 2900035 2 Cap Screw, Hex Hd., 3/8-16 x 3"
18 2900057 2 Cap Screw, Hex Hd., 3/8-16 x 3-3/4"
19 2900321 2 Lock Washer, M10 Split
20 2900325 2 Hex Nut, M10-1.5
21 6030126 1 Spacer, 1"
22 2900595 2 Eyebolt, M10 x 70mm
23 2501100 1 Pulley, 2BK50X1"-4.75" Double Groove w/Setscrews
29
