Diamond Products CC80 User Manual
Page 5
5
MOTOR ASSEMBLY: 6040345
ITEM
PART NO.
QTY
DESCRIPTION
1
2600594
1
2HP-1 Ph Elec. Motor w/ on/off switch, 20A Plug
2
6048229
1
Key, 3/16" Sq. x 1-1/4"
3
6040532
1
Engine Mounting Plate
4
2500034
2
V-Belt, 3VX315
5
2504694
1
Sheave, 3.35-2 Groove (2-3V-3.35-TB)
6
2500030
1
Taper Bushing, 1" w/ Set Screws
7
2505006
1
Sheave, 5.00-2 Groove (3V500SH)
8
2504699
1
Bushing, 5/8" QD SH
9
2501063
2
Bearing, 4 Bolt Flange, 1" ID
10
2900045
4
Lock Nut, 7/16-14 Nylon
11
2900149
4
Cap Screw, Hex Hd., 7/16-14 x 1-3/4"
12
2900005
4
Cap Screw, Hex Hd., 3/8-16 x 1"
13
2900983
4
Cap Screw, Soc. Low Hd., 3/8-16 x 1"
14
2900014
4
Flat Washer, 3/8" SAE
15
2900006
4
Lock Washer, 3/8" Split
16
2900022
1
Flat Washer, 5/16" SAE
17
2900613
1
Cap Screw, Soc. Hd., 5/16-18 x 3-1/4
18
6010487
1
Shaft, Grinding Head
19
6011089
1
Key, 1/4" Sq. x 1" Long
20
2503195
1
O-Ring, Metric M5 x 15mm
21
4699100
1
Cord 50' 12GA, 1 15V 20A Twist to15A Straight
22
2900519
3
Cap Screw, Soc. Hd., 1/4-20 x 1-1/4
23
2900131
2
Set Screw, Soc. Hd., 3/8-16 x 3/8"
ITEM
PART NO.
QTY
DESCRIPTION
1A
2600271
1
Motor, 2HP-1PH Baldor
1 B
2800043
2
Connector, 3/4" Cord
1C
2800309
1
Switch Box Lid W/Gaskets & Screws
1 D
6040347
1
12/3 Cord W/ 20Amp L5-20P Plug
1 E
2800087
1
Plug, Nema L5-20P,125VAC-20Amp
1F
2803200
1
Motor Reset Switch
