Diamond Products CC80 - Manual (Page 3)

Table of Contents
Description Page No.
Motor Assembly………………...………………………………………...4-5
Frame Assembly……………………………………………………………6
Flex Coupling Assembly…………..…………………………………… …7
Guard Assembly….………………………………………………..…….…8
Handle Assembly……….………………………………………………….9
Dust Port Assembly………………………….………..…………………. .10
Decal Group…………………………………………………………….….11
Warranty………………..………………………………………………… .12
Quick Reference Service Filters/ Belts
DP Part No. Description Manufacturer’s Part
2500034 V-Belt (2) for Baldor 2HP, 1PH (Gates #3V315)
Accessories-Floor Grinding Heads
DP Part No. Size Description
GHH0809 8” 9 Segment
