Blade Speed Conversion Charts
WARNING:
Blade Size
Max. Depth
of Cut
No Load RPM Sheave Size No Load RPM Sheave Size
14" 2,800 4" 2,800 4" 4-1/2"
20" 2,500 4.5" 2,800 4" 7-1/2"
26" 2,100 4.5" 2,350 4" 10-1/2"
30" 1,800 6" 2,700 4" 11-3/4"
36" 1,500 6" 2,250 4" 14-3/4"
42" 1,200 6.5" 1,950 4" 17-1/4"
WARNING:
14" 20" 26" 30" 36" 42"
6010950 6010952 6010954 6010956 6010958 6010960
6010658
(4")
6010545
(4.5")
6010545
(4.5")
6013046
(6")
6013046
(6")
6013154
(6.5")
2503959
(3VX500K)
2503959
(3VX500K)
2503959
(3VX500K)
2503960
(3VX530K)
2503960
(3VX530K)
2503960
(3VX530K)
6010036
(4.5")
6010036
(4.5")
6010036
(4.5")
6010038
(6")
6010038
(6")
6017230
(7")
6010037
(4.5")
6010037
(4.5")
6010037
(4.5")
6010039
(6")
6010039
(6")
6017231
(7")
Bottom Set Bottom Set Bottom Set Middle Set Middle Set Top Set
Blade Guard Assembly
When changing blade size, use chart shown below for selecting items that must be changed.
Skid Plate
Mounting Holes
Blade Shaft Sheave
(Sheave Size)
Drive Belts (Set of 10)
(Belt Size)
Inner Flanges (2)
(Flange Size)
Outer Flanges (2)
(Flange Size)
Do not exceed blade speed (RPM) shown for each blade size.
Excessive blade speed could result in blade breakage and serious personal injury!
Blade Shaft Engine
Model CC7172
