Diamond Products CC7172 User Manual
Page 39
Belt Drive Assembly #6013177
V-Belt, AX40
1
2501780
4
V-Belt, AX42
1
2501781
3
V-Belt, 3VX500K (Matched Set of 10)
1
2503959
2
Taper Bushing, 1-3/4" w/Setscrews
1
2501410
Sheave, 4.5" x 10 Groove Taper Style
1
2501381
Sheave, 4.5" x 10 Groove w/Bushing
1
6010545
1
DESCRIPTION
QTY.
PART NO.
ITEM
20" & 26" BLADE DRIVE #6013177B
V-Belt, AX40
1
2501780
4
V-Belt, AX42
1
2501781
3
V-Belt, 3VX530K (Matched Set of 10)
1
2503960
2
QD Bushing, SK x 1-3/4" w/Fasteners
1
2500176
Sheave, 6" x 10 Groove QD Style
1
2500439
Sheave, 6" x 10 Groove w/Bushing
1
6013046
1
DESCRIPTION
QTY.
PART NO.
ITEM
30" & 36" BLADE DRIVE #6013177C
14" BLADE DRIVE #6013177A
ITEM
PART NO.
QTY.
DESCRIPTION
1
6010658
1
Sheave, 4" x 10 Groove w/Bushing
2501380
1
Sheave, 4" x 10 Groove Taper Style
2501410
1
Taper Bushing, 1-3/4" w/Setscrews
2
2503959
1
V-Belt, 3VX500K (Matched Set of 10)
3
2501781
1
V-Belt, AX42
4
2501780
1
V-Belt, AX40
42" BLADE DRIVE #6013177D
ITEM
PART NO.
QTY.
DESCRIPTION
1
6013154
1
Sheave, 6.5" x 10 Groove w/Bushing
2501902
1
Sheave, 6.5" x 10 Groove QD Style
2500176
1
QD Bushing, SK x 1-3/4" w/Fasteners
2
2503960
1
V-Belt, 3VX530K (Matched Set of 10)
3
2501781
1
V-Belt, AX42
4
2501780
1
V-Belt, AX40
