Engine Assembly #6013172
1 2900267 17
Bumper, 1" Dia. x 5/8" Thick 1 2503699 16
Hex Nut, 3/4-10 2 2900041 15
Tap Bolt, Hex Hd., 3/4-10 x 5" 2 2900475
Cap Screw, Hex Hd., M12-1.75 x 80mm 2 10
Cap Screw, Soc. Hd., M8-1.25 x 16mm
18 6013152 1 Oil Drain Valve Assembly
Cap Screw, Hex Hd., 5/8-11 x 3" 4 2900195 11
12
Lock Nut, 5/8-11 Nylon 4 2900135 13
Flat Washer, 5/8" SAE 4 2900002
14
2900346
ITEM PART NO. QTY. DESCRIPTION
1 2600327 1 Engine, Deutz Model TD2011L04i
2 6090417 1 Spacer, 2-1/4" Long
3 2900084 1 Lock Washer, 1/2" Split
4 2900482 1 Hex Nut, M12-1.75
5 2900481 1 Eyebolt, M12 x 6"
6 6010659 2 Engine Support Leg
7 2900347 2 Cap Screw, Hex Hd., M12-1.75 x 100mm
8 2900058 4 Flat Washer, 1/2" SAE
9 2900327 4 Lock Nut, M12-1.75 Nylon Insert
ITEM PART NO. QTY. DESCRIPTION
19 3200814 1 Oil Drain Valve, M18x1.5
20 3200062 1 Hose Clamp #4
21 6013153 1 Oil Drain Hose, 3/8" I.D. x 20"
22 3200741 1 Hose Plug
23 2501434 1 Hose Clamp, 5/8" x 3/4" Wide
24 2900014 1 Flat Washer, 3/8" SAE
25 2900006 1 Lock Washer, 3/8" Split
26 2900005 1 Cap Screw, Hex Hd., 3/8-16 x 1"
