Diamond Products CC7172 User Manual
Page 57
(Includes Items #1 - #23)
2900333
20
2
27
Lock Washer, M10 Split
2
2900321
26
Flat Washer, M10
2
2901356
25
Blade Guard Brace
1
6013072
24
Universal Hinge Assembly
1
6010873
23
Cap Screw, Hex Hd., M16-2.0 x 110mm
1
2901349
22
Lock Washer, M16 Split
1
2900716
21
Flat Washer, M16
1
2901358
Cap Screw, Hex Hd., M10-1.5 x 25mm
ITEM
PART NO.
QTY.
DESCRIPTION
1
6010959
1
36" Blade Guard Front & Rear Only
2
6010081
1
Splash Flap
3
2900310
2
Cap Screw, Hex Hd., M6-1.0 x 20mm
4
2901494
4
Flat Washer, M6
5
2900083
2
Fender Washer, 1/4" x 1-1/4"
6
2900302
6
Lock Nut, M6-1.0 Nylon Insert
7
6010261
1
Water Manifold
8
2500830
1
Water Manifold Gasket
9
2900765
2
Lock Washer, M6 Split
10
2901355
2
Cap Screw, Hex Hd., M6-1.0 x 50mm
11
3200001
3
Plug, 1/8" NPT
12
3200002
1
Fitting, 3/8" M. Pipe to 3/4" M. Garden
13
2900280
1
Lanyard with Lock Pin
14
6010088
2
Water Tube for 36" Guard
15
6048155
2
Water Tube Clamp
16
2900308
4
Cap Screw, Flat Hd., M6-1.0 x 16mm
17
1800001
1
Warning Label
18
1801369H
1
Blade Guard Size Tag
19
2900639
2
Rivet, 1/8" Dia.
ITEM
PART NO.
QTY
DESCRIPTION
28
6010871
2
Hinge Weldment, Universal
29
2900479
1
Cap Screw, Hex Hd., 3/4-10 x 4"
30
2900467
1
Lock Nut, 3/4-10 Nylon
31
2901356
4
Flat Washer, M10
32
2900321
4
Lock Washer, M10 Split
33
2900333
4
Cap Screw, Hex Hd., M10-1.5 x 25mm
34
2503824
1
Detent Pin, 3/4" x 3" Grip
36" Blade Guard Assembly #6010958
57
