Table of Contents
Pictorial Index…………….….……………… 4,5 30hp Motor Assembly………………………. 34
Controls Legend…….…….….……………… 6 30hp Belt Drive Assembly………………….. 35
Notes………………………………………… 7 40hp Motor Assembly………………………. 36
Frame Upright Assembly……….…………… 8,9 40hp Belt Drive Assembly………………….. 37
Instrument Panel Assembly………………….. 10 Rotary Tensioner Assembly…….……………. 38
Water Supply Assembly…………………….. 11 Front Pointer Assembly……………………… 39
Control Lever Assembly……………………. 12 14” Blade Guard Assembly……………….…. 40,41
Control Grip Assembly……………………… 13 20” Blade Guard Assembly…….……………. 42,43
Battery Assembly…………………………… 14 26” Blade Guard Assembly……….…………. 44,45
Hydraulic Pump Assembly……...…………… 15 30” Blade Guard Assembly……….…………. 46,47
Depth Indicator Assembly…………………… 16 36” Blade Guard Assembly……….…………. 48,49
Depth Stop Assembly……………………….. 17 42” Blade Guard Assembly……….…………. 50,51
Frame Lift Assembly………………………… 18 Optional Soft Start Unit Assembly………….. 52
Starter Box Assembly……………………….. 19 Optional Spot Light Assembly………………. 53
Starter Box Unit……………………………… 20,21 Optional Spot Light Assembly………………. 54
Frame Base Assembly………………………. 22 Optional Water Pump Assembly………….…. 55
Hydraulic Cylinder Assembly………………. 23 Optional Parking Brake Assembly……..……. 56,57
Rear Drive Assembly……………………….. 24,25 Optional Blade Stacking Assembly………….. 58,59
Eaton Transmission Assembly……………… 26 Optional Blade Spacing Assembly…………… 60,61
Linkage Assembly…………………………… 27 Optional Blade Spacing Assembly…………… 62,63
Front Axle Assembly………………………… 28 Optional Speed Metering Valve Assembly…… 64
Front Wheel Assembly……………………… 29 Starter Box, DC Travel Option………………… 65
Rear Axle Assembly………………………… 30 DC Power Travel Option ……………………… 66,67
Belt Guard Assembly………………………… 31 Decal Group……………………………….… 69
3 Speed Blade Shaft Assembly……………… 32 Wiring Diagram……………………………… 70
Belt Tensioner Assembly……….…………… 33 Blade Speed Conversion Chart……………… 71
Warranty…………………………….….……. 72
