ITEM PART NO. QTY. DESCRIPTION
1 6011447 1 Frame Lift
2 6010013 2 Frame Lift Brace
3 2900499 1 Cap Screw, Hex Hd., 1/2-13 x 1-1/2"
4 2900106 1 Cap Screw, Hex Hd., 1/2-13 x 2"
5 2900058 3 Flat Washer, 1/2" SAE
6 2900026 2 Lock Nut, 1/2-13 Nylon
7 2900005 1 Cap Screw, Hex Hd., 3/8-16 x 1"
8 2900013 2 Cap Screw, Hex Hd., 3/8-16 x 1-1/4"
9 2900029 1 Cap Screw, Hex Hd., 3/8-16 x 1-1/2"
10 2900018 4 Lock Nut, 3/8-16 Nylon
11 2501603 1 Set Collar, 3/8" with Set Screw
Optional Frame Lift Assembly #6011450
(For Optional Soft Start Unit)
10
3
5
5
5
4
8
1
10
2
7
2
9
10
8
10
6
11
51
