Diamond Products CC3500E (Electric) User Manual
Page 33
20hp Belt Drive Assembly #6011435
14" BLADE DRIVE
ITEM
PART NO.
QTY
DESCRIPTION
1
6011066
1
Pulley, Accessory Drive
2
6011027
1
Key, 3/8" Sq. x 3-1/4" Bevel End
3
2900142
6
Set Screw, Soc. Hd., 5/16-18 x 3/8"
4
6011437
1
Link Belt
5
6011091
1
Sheave, 5.3" x 6 Groove w/Bushing
2500369
1
Sheave, 5.3" x 6 Groove Taper Style
2500368
1
Taper Bushing, 1-5/8" w/Setscrews
6
6012005
1
Sheave, 3.12" x 6 Groove x 1-3/4" Bore
7
2500595
2
Banded Belt, 3/3VX475 - 3 Strand
20" BLADE DRIVE
ITEM
PART NO.
QTY
DESCRIPTION
1
6011066
1
Pulley, Accessory Drive
2
6011027
1
Key, 3/8" Sq. x 3-1/4" Bevel End
3
2900142
6
Set Screw, Soc. Hd., 5/16-18 x 3/8"
4
6011437
1
Link Belt
5
6011092
1
Sheave, 4.75" x 6 Groove w/Bushing
2500367
1
Sheave, 4.75" x 6 Groove Taper Style
2500368
1
Taper Bushing, 1-5/8" w/Setscrews
6
6011009
1
Sheave, 3.65" x 6 Groove x 1-3/4" Bore
7
2500595
2
Banded Belt, 3/3VX475 - 3 Strand
26" BLADE DRIVE
ITEM
PART NO.
QTY
DESCRIPTION
1
6011066
1
Pulley, Accessory Drive
2
6011027
1
Key, 3/8" Sq. x 3-1/4" Bevel End
3
2900142
10
Set Screw, Soc. Hd., 5/16-18 x 3/8"
4
6011437
1
Link Belt
5
6011036
1
Sheave, 4.12" x 6 Groove x 1-5/8" Bore
6
6011010
1
Sheave, 4.12" x 6 Groove x 1-3/4" Bore
7
2500595
2
Banded Belt, 3/3VX475 - 3 Strand
30" BLADE DRIVE
ITEM
PART NO.
QTY
DESCRIPTION
1
6011066
1
Pulley, Accessory Drive
2
6011027
1
Key, 3/8" Sq. x 3-1/4" Bevel End
3
2900142
6
Set Screw, Soc. Hd., 5/16-18 x 3/8"
4
6011437
1
Link Belt
5
6011036
1
Sheave, 4.12" x 6 Groove x 1-5/8" Bore
6
6012052
1
Sheave, 4.75" x 6 Groove w/Bushing
2500367
1
Sheave, 4.75" x 6 Groove Taper Style
2500454
1
Taper Bushing, 1-3/4" w/Setscrews
7
2500595
2
Banded Belt, 3/3VX475 - 3 Strand
