Diamond Products CC3500E (Electric) - Manual (Page 35)

30hp Motor Mount Assembly #6011432
ITEM PART NO. QTY. DESCRIPTION
1 2600182 1 Motor, 30hp Lincoln
2 6011005 1 Engine Base Weldment
3 6011081 2 Motor Spacer
4 6011082 2 Motor Connect Spacer
5 2900105 4 Cap Screw, Hex Hd., 1/2-13 x 2-3/4"
6 2900058 12 Flat Washer, 1/2" SAE
7 2900026 8 Lock Nut, 1/2-13 Nylon
8 2900084 5 Lock Washer, 1/2" Split
9 2900025 1 Cap Screw, Hex Hd., 1/2-13 x 1-1/4"
10 2900192 4 Cap Screw, Hex Hd., 1/2-13 x 2-1/4"
11 2900385 2 Set Screw, Sq. Hd., 5/8-11 x 8"
12 2900112 2 Hex Nut, 5/8-11
13 2900446 2 Swivel Pad Nut, 5/8-11
14 6011022 1 Frame Lift
15 6010013 1 Frame Lift Brace
16 2900127 3 Flat Washer, 1/2" USS
17 2900139 2 Cap Screw, Hex Hd., 1/2-13 x 1-3/4"
18 2900106 1 Cap Screw, Hex Hd., 1/2-13 x 2"
19 2900288 1 Cap Screw, Button Hd., 1/2-13 x 2"
20 2900013 1 Cap Screw, Hex Hd., 3/8-16 x 1-1/4"
21 2900005 1 Cap Screw, Hex Hd., 3/8-16 x 1"
22 2900018 2 Lock Nut, 3/8-16 Nylon
23 2500676 1 Motor Cord Adapter Plate
24 2900201 4 Rivet, 3/16" Dia.
25 2600238 1 Motor, 30hp Lincoln (575 Volt)
35
