Diamond Products CC3500E (Electric) User Manual
Page 37
30hp Belt Drive Assembly #6011436
14" BLADE DRIVE
ITEM
PART NO.
QTY
DESCRIPTION
1
6012019
1
Pulley, Accessory Drive
2
6011095
1
Key, 1/2" Sq. x 3-1/4" Bevel End
3
2900142
6
Set Screw, Soc. Hd., 5/16-18 x 3/8"
4
6011437
1
Link Belt
5
6011093
1
Sheave, 5.3" x 6 Groove w/Bushing
2500369
1
Sheave, 5.3" x 6 Groove Taper Style
2500392
1
Taper Bushing, 1-7/8" w/Setscrews
6
6012005
1
Sheave, 3.12" x 6 Groove x 1-3/4" Bore
7
2500511
2
Banded Belt, 3/3VX500 - 3 Strand
20" BLADE DRIVE
ITEM
PART NO.
QTY
DESCRIPTION
1
6012019
1
Pulley, Accessory Drive
2
6011095
1
Key, 1/2" Sq. x 3-1/4" Bevel End
3
2900142
6
Set Screw, Soc. Hd., 5/16-18 x 3/8"
4
6011437
1
Link Belt
5
6011094
1
Sheave, 4.75" x 6 Groove w/Bushing
2500367
1
Sheave, 4.75" x 6 Groove Taper Style
2500392
1
Taper Bushing, 1-7/8" w/Setscrews
6
6011009
1
Sheave, 3.65" x 6 Groove x 1-3/4" Bore
7
2500511
2
Banded Belt, 3/3VX500 - 3 Strand
26" BLADE DRIVE
ITEM
PART NO.
QTY
DESCRIPTION
1
6012019
1
Pulley, Accessory Drive
2
6011095
1
Key, 1/2" Sq. x 3-1/4" Bevel End
3
2900142
10
Set Screw, Soc. Hd., 5/16-18 x 3/8"
4
6011437
1
Link Belt
5
6012024
1
Sheave, 4.12" x 6 Groove x 1-7/8" Bore
6
6011010
1
Sheave, 4.12" x 6 Groove x 1-3/4" Bore
7
2500511
2
Banded Belt, 3/3VX500 - 3 Strand
30" BLADE DRIVE
ITEM
PART NO.
QTY
DESCRIPTION
1
6012019
1
Pulley, Accessory Drive
2
6011095
1
Key, 1/2" Sq. x 3-1/4" Bevel End
3
2900142
6
Set Screw, Soc. Hd., 5/16-18 x 3/8"
4
6011437
1
Link Belt
5
6012024
1
Sheave, 4.12" x 6 Groove x 1-7/8" Bore
6
6012052
1
Sheave, 4.75" x 6 Groove w/Bushing
2500367
1
Sheave, 4.75" x 6 Groove Taper Style
2500454
1
Taper Bushing, 1-3/4" w/Setscrews
7
2500511
2
Banded Belt, 3/3VX500 - 3 Strand
