Step 3:
The next item to remove is the center console
inner section. This is also held in with clips. We
started by lifting up from the rear of the console at
the backside of the cup holder area.
NOTE: Move shifter to N and insure park break is
set in order to remove console.

This is the area we started to lift the
console up at. It came up easily with a
finger. At this point, there are wired in
clips that you separate under the
console and the console can be removed
and set aside to be reinstalled later.

Step 4: The chrome trim ring must
be slid down next. We used a
plastic flat head screwdriver for
this. TAKE CAUTION and PATIENCE
with this step. Where the arrow is,
there are torx bit screws behind
that portion of the knob. The next
photo will show where the clip is
and where you should start with
the flat head for removal.

Note the location of the clip. If you can get the flat
head in at this point to depress this clip and slide down
on the base it will separate from the top portion of the
knob. This step I took my time as it was a difficult
separation. I used the flat head and went around the
knob trying to insure I didn’t break any clips.

Once this is separate, you’ll have 2 #20 Torx bit screws
exposed. Remove these at this point and the next steps
will show how to remove the knob and base
