MEA Amplifier for Inverse Microscopes Manual

30

Spare Parts

Product

Product
Number

Description

Heating element with 8 mm bore
hole

HE-Inv-8

Heating element with 12 mm bore
hole

HE-Inv-12

Heating element with 23 mm bore
hole

HE-Inv-23

For MEA1060-Inv/MEA1060-Inv-BC amplifier.
Available with bore holes in different sizes,
for using smaller or larger microscope
objectives. The smallest size has the best
temperature controlling properties.

Heating element

HE-Up

For MEA1060-Up/MEA1060-Up-BC amplifier

Cable assembly

CA

For HE-Inv or HE-Up

0.5 m 68-Pin MCS Standard cable

C68x0.5M

1 m 68-pin MCS Standard cable

C68x1M

3 m 68-Pin MCS Standard cable

C68x3M

For MEA- or ME-Systems

Ag/AgCl pellet

P1060-Inv

For MEA1060-Inv/MEA1060-Inv-BC amplifier

Ag/AgCl pellet

P1060-Up

For MEA1060-Up/MEA1060-Up-BC amplifier

Ag wire

W1060-Inv

For MEA1060-Inv/MEA1060-Inv-BC amplifier

Ag wire

W1060-Up

For MEA1060-Up/MEA1060-Up-BC amplifier

Solder lug

SL1060-Inv

For MEA1060-Inv/MEA1060-Inv-BC amplifier

Gold spring contacts

GSC1060-Inv

For MEA1060-Inv/MEA1060-Inv-BC amplifier

Gold spring contacts

GSC1060-Up

For MEA1060-Up/MEA1060-Up-BC amplifier

Gold spring contact comb

GSCC1060-Up

For MEA1060-Up/MEA1060-Up-BC amplifier

3-Pole cable (from STG to
MEA1060)

C3P

With ground, not necessary for MEA1060BC
amplifiers

Red single pole cable (from STG
to MEA1060)

CR

Black single pole cable (from STG
to MEA1060)

CB

MEA-Systems

Product

Product
Number

Description

MEA recording system for
inverted microscopes,
60 electrode channels

MEA60-Inv-
System

Complete with 5 MEAs, data acquisition
computer with MC_Card, MEA1060-Inv
amplifier, TC01, power supply, and accessories

MEA recording system for
inverted microscopes,
60 electrode channels, 2
MEA amplifiers

MEA60-Inv-2-
System

Complete with 5 MEAs, data acquisition
computer with MC_Card, 2 x MEA1060-Inv
amplifier, MEAS2/1, TC02, power supply,
and accessories

MEA recording system for
upright microscopes,
60 electrode channels

MEA60-Up-
System

Complete with 5 MEAs, data acquisition
computer with MC_Card, MEA1060-Up
amplifier, TC01, power supply, and accessories

MEA recording system for
upright microscopes,
60 electrode channels

MEA60-Up-2-
System

Complete with 5 MEAs, data acquisition
computer with MC_Card, 2 x MEA1060-Up
amplifier, MEAS2/1, TC02, power supply,
and accessories

MEA recording system for
inverted microscopes with
advanced perfusion,

MEA60-Inv-
System-E

Complete with 5 MEAs, data acquisition
computer with MC_Card, MEA1060-Inv
amplifier, TC02, PH01, power supply,
