23

7 Appendix

7.1 Technical

Specifications

7.1.1 MEA1060-Inv

Operating temperature

10 °C to 50 °C

Storage temperature

0 °C to 50 °C

Dimensions (W x D x H)

165 mm x 165 mm x 20 mm (29 mm with sockets)

Weight 800

g

Supply voltage (external power
supply)

± 6 VDC to ± 9 VDC

Supply current

max. 220 mA, typically ± 150 mA

Number of stimulus input channels

60

Maximum recommended stimulus
input voltage

± 5 V

Number of analog input channels

60

Input voltage

-4 mV to 4 mV (with respect to the standard gain of 1200)

Input impedance

10

11

 parallel to 10 pF

Input noise

< 800 nV

RMS

Noise density

e

n

= 15 nV / Wurzel aus Hz

Number of analog output channels

60

Output voltage

± 5 V

Output current

10 mA

Output impedance

300

Bandwidth

1 Hz to 3000 Hz (standard), 1 Hz to 5000 Hz (custom)

Gain

1200 (standard), 500 to 5000 (custom)

Microscope compatibility Inverse

microscopes

Distance focal plane to microscope table

3.5 mm
