ENGLISH
13
Name
It is possible to choose and set a name to display instead of the channel number. It is possible to set the name
only by the G14 programming software. Once set, by the radio is possible to enable or disable it choosing “on” or
“ off”.
BATTERY RECHARGE
G14 is equipped for using a 7,4V LI-ion rechargeable battery pack which can be recharged connecting the socket
of the AC/DC wall adaptor to a mains power socket and insert the jack of the wall adaptor into the desktop charger
plug.
It takes 4-5 hours to fully recharge the radio.
For maximum battery life, we recommend charging the battery pack when the G14 is off and the low battery icon
comes on.
! Using a different battery charger other than the one specified can cause damage to your device or may
even cause explosions and personal injuries.
BATTERY LEVEL INDICATOR
G14 has a BATTERY LEVEL METER that shows the battery power level.
The greater is the number of bars visible, the stronger will be the battery level. When the battery level is low, the
Battery icon will flash in the display, indicating that your batteries should be recharged.
The battery power saving feature enables a reduction in consumption of up to 50%; power saving comes on auto-
matically when the transceiver does not receive any signal for more than 7 seconds.
MAINTENANCE
Your G14 was designed to fulfill any warranty obligations and to enjoy this product for many years.
Do not attempt to open the unit. Non-expert handling of the unit may damage it. •
When using regulated power supply, take notice of power voltage, that must be between 6V and 8V to avoid •
damages.
High temperatures can shorten the life of electronic devices, and warp or melt certain plastics.
•
Do not store the radio in dusty or dirty areas. •
Keep the Radio dry. Rainwater or damp will corrode electronic circuits. •
If it appears that the Radio diffuses peculiar smell or smoke, please shut off its power immediately and take off •
the charger or battery from the Radio.
Do not transmit without antenna.
•
SPECIFICHE TECNICHE
General
Frequency range
446.00625- 446.09375 MHz (PMR)
Working temperature -20° +50°
Operating voltage 7.4V
Operate mode Simplex
Dimensions 100mm×58mm×33mm (Antenna excluded)
Weight 203g (battery included)
Antenna impedance 50Ω
Duty cycle 5/5/90%
Transmitter
Frequency stability
±2.5PPM
Output power ≤500mWERD
Max frequency deviation ≤ 2,5KHz
Audio distortion ≤ 3%
Adjacent channel power < 60 dB
Spurious radiation Within European legal terms
Occupied bandwidth Within European legal terms
Receiver
RF sensibility
≤ 0.2UV@20 dB SINAD
Audio distortion ≤ 3%
Audio response 300Hz ÷ 3KHz
Adjacent channel selectivity Within European legal terms
Intermodulation rejection Within European legal terms
Spurious response Within European legal terms
Blocking Within European legal terms
