Panel trasero, Micrófono, Esp añol – MIDLAND 220 User Manual
Page 28
28
ESP
AÑOL
PANEL TRASERO
14. Conector de antena: tipo SO239 ó PL
15. Jack ”EXT”: jack para conexión de un altavoz externo opcional (anula el altavoz de la radio).
16. Jack S-Meter: permite la conexión de un “S-Meter” externo opcional.
17. Alimentación 12.6V DC: cable de alimentación.
MICRófONO
1. PTT: tecla de transmisión o pulsar para hablar.
2. Mandos uP/DOWN: teclas de cambio de canal.
3. Conector de micro de 6 pin.
EXT-SP
S-METER
ANT
+RED
-BLK
14
15
16
17
EXT-SP
S-METER
ANT
+RED
-BLK
2
1
3
