Mody Pumps M 100 T_316SS SERIES User Manual
Page 15
PUMP MODELS M100T/100ST/106T/106ST/120T/126T
Ref : Drawing no. DW/041/00
D.NO.
PART NO.
DESCRIPTION
QTY
43a
405-036-24
OUTLET 2" NPT SS
1
43b
405-009-24
OUTLET 2" HOSE SS
1
43c
405-033-24
OUTLET 2" BSPT SS
1
44a
065-014-79
CABLE 100/106/120/126
50'/20m
44b
065-015-79
CABLE 100ST/106ST (115V)
50'/20m
44c
14/6
CABLE 6 CORE
50'/20m
45
650-004-24
STUD
2
46
465-006-21
RIVET
6
47
350-015-21
NAME PLATE
1
48
635-010-21
ROTATION ARROW
1
49
045-006-24
HEX. HD. BOLT
2
50
650-003-24
STUD
2
51
365-025-00
WIRE NUT CONNECTER
3
52
365-026-00
WIRE NUT CONNECTER
3
53
365-027-00
WIRE NUT CONNECTER
2
54
535-033-00
MECHANICAL SEAL
2
55
080-002-21
CIRCLIP
2
56
525-025-24
PH.PAN HD.SCREW
3
57
590-003-66
SLINGER
1
58
600-076-24
CAP FOR CIRCLIP
1
59
515-010-21
SAND GUARD
1
60
395-005-93
OIL
0.2 ltrs
61
660-110-00
AIR VOLUME COMPLETE (61a & 62)
1
61a
340-004-66
AIR VOLUME
*
62
310-022-32
INSERT FOR AIR VOLUME
*
63
430-034-66
CAP FOR OUTLET
1
64
375-100-74
"O" RING SET
1
