Mody Pumps M 100 T_316SS SERIES User Manual
Page 14
PUMP MODELS M100T/100ST/106T/106ST/120T/126T
Ref : Drawing no. DW/041/00
D.NO.
PART NO.
DESCRIPTION
QTY
1
270-017-24
HANDLE
1
2
045-007-24
HEX. HD. BOLT
2
3
700-002-24
WASHER
18
4
035-005-24
TOP BRACKET
1
5
380-084-74
"O" RING
2
6
380-023-74
"O" RING
3
7a
400-001-24
OUTER CASING (M100T/106T)
1
7b
400-002-24
OUTER CASING (M100ST/M106ST)
1
7c
400-003-24
OUTER CASING (M120T/126T)
1
8a
625-001-24
STATOR CASING (M100T/106T)
1
8b
625-002-24
STATOR CASING (M100ST/106ST/120T/126T)
1
9a
480-076-00
ROTOR COMPLETE (M100T/106T)
1
9b
480-071-00
ROTOR COMPLETE (M100ST/106ST/120T/126T)
1
10a
619-002-00
BARE STATOR (M100T/106T)
1
10b
619-062-00
BARE STATOR 575V (M100T/106T)
1
10c
619-004-00
BARE STATOR (M100ST/106ST)
1
10d
619-006-00
BARE STATOR (M120T/126T)
1
10e
619-007-00
BARE STATOR 575V (M120T/126T)
1
11
045-001-24
HEX. HD. BOLT
4
12
037-001-24
BEARING COVER
1
13
020-004-07
LOWER BEARING
1
14
035-074-24
LOWER BEARING BRACKET COMPLETE
1
15
660-034-00
STUD ASSY.
4
16
545-019-24
SEAL HOUSING COMPLETE
1
17
715-001-24
WEAR PLATE
1
18
370-005-24
HEX. NUT
12
19a
300-017-24
IMPELLER M100T/M100ST (50Hz)
1
19b
300-018-24
IMPELLER M100T/M100ST (60Hz)
1
19c
300-088-24
IMPELLER M106T/M106ST (60Hz)
1
19d
300-020-24
IMPELLER M120 (50Hz)
1
19e
300-021-24
IMPELLER M120 (60Hz)
1
19f
300-090-24
IMPELLER M126 (60Hz)
1
20
175-015-24
DIFFUSER
1
21
640-007-24
STRAINER
1
22
365-038-24
DOME NUT
1
23
320-002-22
KEY
1
24
600-009-24
TRIMMING SPACER
3
25
520-002-24
OIL PLUG
2
26
380-001-74
"O" RING
2
27
020-002-07
UPPER BEARING
1
28
380-012-74
"O" RING
1
29
525-007-40
EARTHING SCREW
1
30
740-001-46
CABLE LUG
1
31
235-007-24
CABLE GLAND BASE
1
32
260-016-66
CABLE LEAD GROMMET
1
33
380-005-74
"O" RING
1
34
380-009-74
"O" RING
1
35
380-007-74
"O" RING
1
36
220-003-66
GASKET (OUTLET)
1
37
600-011-24
CABLE GLAND SPACER
1
38
260-034-66
CABLE GROMMET
1
39
230-001-24
CABLE GLAND
1
40
085-003-24
CABLE CLAMP
2
41
370-002-24
HEX. NUT
2
42
525-022-24
PH.PAN HD.SCREW
2
