Page Number - 3 Form 822823
Always read instructions carefully prior to use.
Recommended Fluids:
Engine Oil, Gear and Transmission Oils, Power Steering Fluid, Coolants, Brake Fluid and Other Similar
Fluids.
DO NOT USE WITH GASOLINE.
The reservoir tank of the Fluid Evacuator Plus is equipped with an automatic shut-off valve to pre-
vent over-filling of the reservoir tank. As the fluid being evacuated flows into the reservoir tank it will
raise the float. When the float reaches the shut-off valve, the flow of fluid being extracted will auto-
matically stop.
Extracting from and Dispensing Motor Oil into a Crankcase
1. Park vehicle on level ground, ensure the transmission of the vehicle is in “neutral” or “park” posi-
tion and apply the parking brake.
2. Start the engine. Allow the engine to idle until it reaches normal operating temperature. Once
this is accomplished, turn engine off.
3. Remove the engine oil dipstick.
4. Select and insert the smallest diameter dipstick tube into the dipstick hole until it reaches the bot-
tom of the oil pan. Connect the main suction tube to the dipstick tube.
5. Insert the opposite end of the main suction tube into the 10mm x 90° tube connector on the top of
the reservoir tank. Take care that tube is in the connector all the way to prevent leakage.
6. Place the selector valve mounted on the side of the pump assembly to “EVACUATE”.
7. Raise the pump handle on the reservoir tank until it reaches its highest limit. Pump the handle ap-
proximately ten times. The unit will begin to extract the oil from the engine crankcase.
NOTE: Due to the varying fluid capacities of engines, it may be necessary to empty the fluid res-
ervoir tank and restart the process if the crankcase capacity exceeds 8 liters.
8. Once the oil has been extracted from the crankcase, remove the expandable rubber plug from
the reservoir tank; pour the oil from the tank into a suitable container, and dispose of the oil in an
appropriate manner. Rinse out the reservoir tank with clean solvent or engine degreaser. Allow
it to dry thoroughly.
9. If you wish to use the Fluid Evacuator Plus to dispense oil, fill the cleaned reservoir tank with
new oil and simply switch the selector valve that is mounted on the side of the pump assembly to
“DISPENSE”.
10. Pull up on the pump handle and begin pumping until the engine crankcase is filled to the desired
level.
11. Run the engine momentarily to circulate the new oil and then re-check the level.
MAXIMUM TEMPERATURE OF FLUIDS:
176° Fahrenheit (80° Celsius)
