26
Machine Overview
1. Brush Deck may be tilted up for easier
brush installation/removal & to clear
steep ramps. Lift the handle on the
upper lever which connects the brush
deck to the machine, tilt the deck up,
release the handle & the lever will lock
into place. Lift the handle again to move
the deck back to horizontal.
2. Brushes are installed/removed by hand.
Push each brush up onto the hub until
it “clicks”. To remove, pull down on the
edge of each brush.
3. The splash guard may be moved up or
down as the brush/pad wears by loos-
ening the clamp on the back side of the
deck with a flathead screwdriver or 9/
32” (7mm) socket, then slide the splash
guard to the desired height & retighten
the clamp.
Brush Loading / Unloading
Brush Deck
