14
Machine Overview
The battery compartment is located under the recovery tank. The
Battery compartment can be accessed for servicing and mainte-
nance by tilting the recovery tank (make sure recovery tank has
been drained before tilting). The battery compartment contains
two 12-volt batteries connected in series. Connect the batteries
according to the battery connection diagram (see diagram). The
recommended batteries are 140Ah (Minuteman P/N 956140) or
95Ah (minuteman P/N 956100) Gel. The battery tray may be
drained if necessary using the orange drain hose located above
the rear caster on the right side of the machine.
Battery Compartment
