Minuteman Kleen Sweep 40R-47R HM50QP User Manual
Page 71
Dirt hopper - Dirt hopper lifter
Item
PN
Qty.
1
01130050
1
Holder, l.h.
2
00051510
10
Hex. nut
3
00042900
12
Washer
4
00878410
2
Cup square bolt
5
00053750
6
Washer
6
00103300
6
Socket head cap screw
7
01130060
1
Handle
8
01130070
9
Bush
9
01130080
9
Slide bearing bush
10
00101500
2
Countersunk screw
11
01130090
1
Holder, l.h.
12
00053100
2
Hex. bolt
13
01130200
1
Gasket
14
01130300
1
Angle, l.h.
15
00045540
4
Socket head cap screw
16
01130100
1
Plate
17
01130310
1
Angle, r.h.
18
01130110
1
Nut
19
00750430
2
Edge protector profil
20
01130120
1
Sealing plate
21
00077110
1
Hex. bolt
22
01130130
1
Pull spring
23
01130140
1
Holder, r.h.
24
00874930
2
Protective cap
25
01130150
1
Holder, r.h.
26
01130160
1
Plate
27
01130170
4
Bush
28
01130180
2
Handle
29
00078920
4
Saucer head screw
30
01130190
2
Dirt hopper
71
