Minuteman Kleen Sweep 40R-47R HM50QP User Manual
Page 69
Fan bearing
Item
PN
Qty.
1
00506780
1
Threaded pin
2
01131220
1
Rotating fan
3
01131230
1
Shaft
4
00053010
3
Hex. bolt
5
03003350
1
Bearing plate
6
01131240
1
Bearing bush
7
00740280
3
Detent washer
8
00053330
3
Hex. nut
9
00706360
1
Cylindrical bearing
10
00126320
1
Retaining ring
11
01131250
1
Distance tube
12
00538360
1
Cylindrical bearing
13
01131260
1
Belt pulley
14
00740090
1
Detent washer
15
00022330
1
Hex. nut
16
00074710
2
Hex. nut
17
00740290
1
Detent washer
18
01131270
1
Holder
19
00740090
2
Detent washer
20
00553690
2
Hex. bolt
21
01130970
1
Idler
22
00126330
1
Cylindrical bearing
23
00021800
1
Countersunk screw
69
