12
Machine Overview
A B C D E
F
Brush Speed Keyswitch & Circuit Breakers
A Main Control Circuit Breaker - 4A
B Brush Motor Circuit Breaker - 50A
C Vacuum Motor Circuit Breaker - 20A
D Drive Motor Circuit Breaker - 20A
The circuit breakers are located at the bottom of the back
panel of the machine.
If any of the functions above are not operating, check if the
circuit breaker buttons have tripped. Press to reset.
E Brush Speed Keyswitch
F High RPM LED Indicator
When the key is turned to the right, the brush will rotate at
high speed and the LED will illuminate.
The low speed is for standard cleaning with or without the brush deck weights.
The high speed is for stripping, polishing and special cleanning processes.
NOTE: DO NOT LOAD OR UNLOAD BRUSH FROM MACHINE WITH LED LIT.
DAMAGE TO BRUSH OR BRUSH MOTOR HUB MAY OCCUR.
