Parts and Instruction Manual - Mirage 27” Propane Burnisher Page 20
Mirage 27” Propane Burnisher
Parts List Cont’d.
ITEM NO. PART NUMBER DESCRIPTION QTY.
7.5 W1200 MINUTEMAN DECK DECAL 1
7.6 W1199 MINUTEMAN NAME PLATE W/ SERIALIZATION 1
7.7 W4241 REAR CASTER 2
7.8 W4210 DELUXE WHEEL BRACKET (5-HOLE) 2
7.9 W4220 RUBBER WHEEL, 6” X 1 ½” 2
7.10 W4218 3/8” COLSON WHEEL BUSHING 2
7.11 F37023 3/8 – 16 SELF-LOCKING HEX JAM NUT 2
7.12 W4221 AXLE FOR COLSON WHEEL 2
7.13 F58969 6mm X 32mm PARALLEL KEY 1
7.14 W4108 27” FRONT BUMPER STRIP 1
7.15 MC8507K24 NEOPRENE RUBBER EDGING 1
7.16 MC93625K95 NATURAL GUM FOAM-ADHESIVE 1
7.17 F33006 FLAT WASHER, WIDE, 5/16” 12
7.18 F13107 HEX BOLT, 3/8 – 16 X 1 ¼” 5
7.19 F33622 LOCKWASHER, HELICAL, 3/8” 5
7.20 F24225 FHCS, ¼ - 20 X 1”, HEX SOCKET 8
7.21 F24256 FHCS, 5/16 – 18 X 1”, HEX SOCKET 8
7.22 F25469 SET SCREW, HEX SOCKET, 5/16 – 18 X 3/8” 2
7.23 F37018 ¼ - 20 SELF-LOCKING HEX JAM NUT 8
7.24 F37021 5/16 – 18 SELF-LOCKING HEX JAM NUT 8
8 F0216763 C-LOOP, ¼” 1
9 F58969 6mm X 32mm PARALLEL KEY 1
10 F33006 FLAT WASHER, WIDE 5/16” 4
11 F13111 HEX BOLT, 3/8 – 16 X 2” 5
12 F38565 HEX WASHER BOLT, M6 X 20mm 1
13 F37021 5/16 – 18 SELF-LOCKING HEX JAM NUT 4
14 F33624 HEAVY LOCKWASHER, HELICAL, 3/8” 1
15 F33622 LOCKWASHER, HELICAL, 3/8” 5
16 F33620 LOCKWASHER, HELICAL, 5/16” 4
17 F21255 CARRIAGE BOLT, 5/16 – 18 X 1” 4
18 F24089 BUTTON HEAD CS, 3/8 – 16 X 5/8” 1
19 WBX53 V-GROOVE BELT, 5/8” X 53” 1
20* W4076-PP WIRING HARNESS 1
*ITEM SHOWN ON SEPARATE WIRING DIAGRAM SHEET
