Operation
F232172
16
© Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT
Operating Instructions, OPL Models
Only
1. Turn on main power source (circuit breaker) with
right hand.
2. With left hand, push and hold white rocker
3. Push button and turn handle clockwise to open.
Refer to Figure 10.
Figure 10
4. Load to capacity whenever possible. DO NOT
OVERLOAD. Refer to Figure 11.
NOTE: Underloading can cause out-of-balance
conditions that can shorten machine life.
Figure 11
5. Close door and turn handle counterclockwise
until button pops out. Refer to Figure 12.
Figure 12
6. The default wash cycle will display. Refer to
NOTE: Perm Press Hot is the default cycle if none
is selected.
Figure 13
CHM2027N
1
Rocker Switch
2
Handle
U003I
2
1
U005I
CHM522N
CHM1764C
To avoid personal injury, recommended
inlet water temperature should be no
higher than 125° Fahrenheit (51° Celsius).
W709
WARNING
WASH
ADD
BLEACH
RINSE
SPIN
DOOR
CLEAN
FILTER
NORMAL
LIGHT SOIL
UNIFORMS
HEAVY SOIL
STAINED
DELICATE
HOT
HOT
HOT
HOT
HOT
HOT
WARM
COLD
START
PERM PRESS
VISA
TM
DOMESTIC MODELS
CHM1764C
60C
60C
40C
40C
95C
95C
<
<
30C
INTERNATIONAL MODELS
