SPECIFICATIONS
Output Voltage Range
272-5X5 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .0 to 10V Typical
272-5X7 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .0 to 10V Typical
272-5X8 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .0 to ± 10V Typical
13.5 V Maximum
Accuracy
Linearity (input RPM vs Output Voltage) . . . . . . . . . . . . . . . . .0.05% Typical
0.10% Maximum
Zero Offset (Referred to Output: 0 to 10 V) . . . . . . . . . . . . . . . . .3mV Typical
5mV Maximum
Temperature Range
272-5X5 and 272-5X7
Electronics:
Operating . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .-10°C to 65°C
Storage . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .-40°C to 70°C
Stator . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . -40°C to 130°C
272-5X8
Electronics:
Operating . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .-10°C to 65°C
Storage . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .-40°C to 70°C
Stator . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .-40°C to 90°C
Temperature Coefficients
Flow Meter Magnet . . . . . . . . . . . . . . . . . . . . . . . . . .0.5% per 100°C
Transmitter . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .0.2% per 100°C
Zero (Referred to Output: 0 to 10 V) . . . . . . . . . . . . .1 Mv per 100°C
Supply Voltage and Current *
272-5X5 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .±15V±5% @ 5.9mA
272-5X7 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .±15V±5% @ 23mA
272-5X8 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .±15V±5% @ 26mA
* Substitution of op amps will increase current consumption slightly. See schematic tables.
272-500-350 © 1996 (Rev. 8/00) Max Machinery, Inc. Page 3
Discontinued
