Specifications
Indoor Fiber Distribution Terminals - CPE
Interior Wall Mount Terminals
IFDT-12 IFDT-24 IFDT-48 IFDT-72 IFDT-96
Fibers (nominal) 6 and 12 24 48 72 96
Adapter Panels 2 APLH 2 APLH 4 APLH 6 APLH 8 APLH
Splice Trays 1/12f 2/12f 4/12f 6/12f 8/12f
Cable Ports 2 slotted 4 slotted 4 slotted 4 slotted 4 slotted
Grip Clamps 2 4 4 4 4
Jumper Ports 2 slotted 2 slotted 2 slotted 2 slotted 2 slotted
NEMA Rating 12 12 12 12 12
Height 7.0 in.
(17.8 cm) 8.0 in.
(20.3 cm) 18.5 in.
(47.0 cm) 24.5 in.
(62.2 cm) 32.0 in.
(81.2cm)
Width 12.0 in.
(30.5 cm) 14.0 in.
(35.5 cm) 13.0 in.
(33.0 cm) 13.0 in.
(33.0 cm) 13.0 in.
(33.0 cm)
Depth 3.0 in.
(7.6 cm) 5.0 in.
(12.7 cm) 5.0 in.
(12.7 cm) 5.0 in.
(12.7 cm) 5.0 in.
(12.7 cm)
Weight (Empty) 5.0 lbs
(2.3 kg) 7.0 lbs
(15.4 kg) 12.8 lbs
(28.2 kg) 16.0 lbs
(35.2 kg) 20.0 lbs
(44 kg)
Color CO White CO White CO White CO White CO White
