Alcatel-Lucent 1850 TSS-160 | Release 3 | Data Sheet 2
Technical specifications
Alcatel-Lucent 1850 TSS-160
system
Alcatel-Lucent 1850 TSS-160
subrack
• 8 slots, 20 Gb/s per slot: 16 half
slots, 10 Gb/s per half slot
• Two 160 Gb/s protected switching
fabrics
• Two protected controllers
• Protected power supply
• Up to three subracks in a standard
eTSi or AnSi rack
Interfaces
• Data cards
¬ 10 x Gigabit Ethernet (GE)
packet module, Small Form-
Factor pluggable (SFp)
¬ 10 GE packet module, 10 Gb/s
Form-Factor pluggable (XFp)
¬ Multiservice packet over
SONET/SDH (PoS) packet
module, portless
¬ ATM gateway packet module,
portless
• SONET/SDH cards
¬ 1 x OC-192/ STM-64: XFP
¬ 4 x OC-48/STM-16: SFP
¬ 8 x OC-3-12/STM-1-4: SFP
¬ 10 x any port card: a data/TDM
concentrator: SFP
¬ 1 x optical transport unit
(OTU)-2: 10 Gb/s bidirectional
transponder, tunable optics
• VLH/ULH cards
¬ 10 Gb/s booster +10 dBm
¬ 10 Gb/s pre-amp +10 dBm
• Fixed OADM (FOADM) DWDM
cards (packs)
¬ 8 channels MUX/DEMUX,
L1 band
¬ 8 channels MUX/DEMUX,
L2 band
¬ Optical amplifier 22/9 17 dB
¬ 10 G transponder, client and
line pluggable: XFP
• ROADM DWDM cards (packs)
¬ optical protection switch
¬ DwDM RoADM wavelength
router
¬ DWDM transponder: tunable
line optics, XFp client
¬ DWDM MUX/DEMUX
¬ DwDM amplifier
• Delivers multidegree reconfigu-
rable optical add/drop multiplexer
(ROADM) functionality
¬ Reconfigurable 44 x 10 G channel
DWDM
¬ Wavelength selective switch (WSS)
1 x 9 ports
¬ Mesh capable ROADM up to
8 degrees
Benefits
• Switches any combination of packets
and circuits in their native formats
using a single platform
• Fully scales packet transport, smoothly
progressing from all-circuit to all-
packet, allowing service providers
to transform networks to packet
transport
• Efficiently aggregates and grooms
metro and long-haul transport
• Simplifies network planning using
ROADM and WDM
• Reduces total cost of ownership and
simplifies operations through cross-
layer network management and
unified control plane
• Supports a broad range of applica-
tions, such as triple play services,
business Ethernet and mobility
backhaul
Service level agreement (SLA)
management
• Traffic profiles
¬ Bandwidth guaranteed
¬ Regulated: minimum band-
width guaranteed plus burst
¬ Best effort
• Hitless traffic-profile modification
• Metering
¬ Single Rate Token Bucket:
RFC 2697
¬ Dual Rate Token Bucket:
RFC 2698
¬ ieTF and Metro ethernet Forum
(MeF) Metering, policing and
Marking
¬ Color-blind and color-aware,
based on ethernet priority bits
Ethernet functionality
• Ethernet protocol: 802.3
• Ethernet Media Access Control
(MAC) autolearning and aging
• Ethernet-MAC static configuration
• Access Control List (ACL)
• Virtual LAN (VLAN) push, pop,
swap: service delimiting
• Ethernet virtual bridging: 802.1Q
• Ethernet provider bridging: 802.1ad
• Q in Q
• Rapid Spanning Tree Protocol
(RSTp) and Multiple Spanning
Tree protocol (MSTp)
• Link aggregation
• Jumbo-frame management
• Y.1731/802.1ag OAM: continuity
check (CC), link trace (LT),
loopback (LB)
• 802.3ah OAM: Ethernet in the
first mile (eFM)
• Eight Quality of Service (QoS)
classes
• Two levels QoS: per class, per
transport service
• Ethernet flow, RGY counters
• L2 control protocol filtering/
tunneling
• Metro Ethernet Forum (MEF) 9
and MEF 14 certified: EPL, EVPL
and e-LAn
Ethernet traffic classification
• Port
• Ethernet VLAN
• Ethernet priority bits
• IP v4 differentiated services
code points (DSCp)
• EtherType
• MPLS Exp bits
