Agri-Fab 45-0351 - Manual (Page 8)

8
oPeraTIon maInTenanCe
1. Check for loose fasteners before each use.
2. At the beginning of each season, lubricate the latch, the
latch pivot bolt, and the bearings in the walking beams
with a light machine oil.
3. Grease the wheel bearings periodically. Use general
purpose grease.
4. Keep tires filled to the pressure recommended on the
tires. 1. Refer to the vehicle operator's manual for instructions
on safe operation on slopes.
2. Always operate at reduced speed on slopes.
3. Do not operate an ATV towing the cart on a slope greater
than 15 degrees.
4. Do not operate a tractor towing the cart on a slope
greater than 10 degrees. Use the slope guide on page
9 of this manual.
10. To dump material from the cart, remove the tailgate by
lifting it straight up and out from between the guides.
Release the spring latch on the tongue by pulling the
latch lock lever forward, away from the cart. The cart
bed will then tilt backwards to empty its contents. After
emptying, pull the front of the bed down toward the cart
tongue until the latch snaps into place. Replace the
tailgate if desired.
Do noT eXCeeD weIGHT CaPaCITY oF CarT
(See the specifications on this page for each model)
One cubic foot of dirt weighs approximately 80 lbs. moDel 45-0350 aTV CarT
Tires: 18.00" x 9.5" Knobby Tread
axle: 1.0" Dia. High Carbon Steel
Capacity: Up to 1000 Lbs. Max.
approx. sh. wt. 208 Lbs.
moDels 45-0351 Farm CarT
Tires: 16.00" x 6.5" Turf Tread
axle: 1.0" Dia. High Carbon Steel
Capacity: Up to 1000 Lbs. Max.
approx. sh. wt. 195 Lbs.
CarT moDel sPeCIFICaTIons
CauTIon: Vehicle braking and stability may
be affected with the addition of an accessory
or an attachment. Be aware of changing
conditions on slopes.
noTe
CauTIon: To avoid possible injury, before
releasing the latch be sure that no one is
near the cart.
CauTIon: Do not exceed the towing
capacity of the vehicle. Follow any weight
limitations listed in the vehicle operator's
manual.
5. For best handling and traction, distribute the weight of
the load evenly in the cart.
6. Always test to make sure your vehicle has adequate
towing and braking capabilities when towing a load in your
cart. Use extra caution when operating on slopes.
7. Operate at reduced speed when towing a load.
8. The 45-0350 cart should not exceed 20 m.p.h., or your
vehicle's maximum safe towing speed, whichever is
less. Refer to your vehicle operator's manual.
9. The 45-0351 cart should not exceed 10 m.p.h., or your
vehicle's maximum safe towing speed, whichever is
less. Refer to your vehicle operator's manual.
