MAP Technology Install User Manual from CD
PN 89-00002-00-028 Rev. B 5
.
Figure 5 Connecting the PC, Mouse, Barcode Reader, and Keyboard
Power On PC
Components
Power on the PC and monitor (power switches on front):
After you power on the PC, Microsoft ® Windows ® automatically
starts up. In a moment the Luminex 100 IS software License dialog
box appears. Select Decline to exit the dialog box. Continue with the
section “Install User Manual from CD” on page 5.
Install User Manual
from CD
‹
To install the Luminex 100 IS user manual:
1. Insert the Luminex 100 IS User Manual CD into the drive. In a
few moments the CD autoplays and displays the installation
window. Follow the on-screen directions. If the installation
window does not appear, in the bottom left corner of the screen
select Start>Run. In the Open: box, enter D:launch and click
OK.
2. If the Luminex License dialog box appears, click Decline at this
time. If the Luminex 100 IS 2.3 software automatically starts up,
from the File menu, select Exit to close the software. See
caution.
1
2
3
4
1. Keyboard 3. Y-Cable
2. Barcode Reader 4. Mouse
Note: Adobe Reader is
automatically installed as part
of the user manual installation.
Caution: The on-line help files are automatically installed
during this procedure. You must close the Luminex 100 IS 2.3
software at this time or the help file will not be installed.
