15
ASSEMBLY OF GRANIT COAT GUN GMX-2000
Flush Valve Assembly (5104-01-01)
See Drawing Flush Valve Assembly (5104-01-01) for reference
1. Install the O-Ring (7301-13-008)* onto the Flush Valve Button (5104-25-1)
2. Install the O-Ring (7301-3-007) onto the Flush Seal Body (5104-23-1)
3. Install the Compression Spring (9203-2-3) into the Flush Valve Body (5104-24-1)
4. Push the Flush Valve Button (5104-25-1) through the Compression Spring (9203-2-3)
located in the Flush Valve Body (5104-24-1), and screw on and tighten the Flush Seal
Body (5104-23-1)
5. Install the Flush Valve Seal (5104-26-1) onto the Flush Valve Body (5104-24-1) and
thread through the Flush Valve Neck (5104-22-1)
6. Install the Flush Elbow Assembly (5104-02-01) onto the Flush Valve Neck (5104-22-1)
7. Install the Flush Valve Split Seal (5104-21-1) onto the Flush Valve Body (5104-24-1)
Note: O-Ring (7301-11-008) KALREZ use with any solvent. * In some cases O-Ring (7301-
13-008) EPR can be substituted for as a less expensive alternative - DO NOT USE GREASE
WITH EPR O-RING
.
Catalyst Injector Assembly (5104-03-01) Assembly
See drawing Injector Assembly (5104-03-01) for reference
1. Slide Injector Plunger (5104-16-1) thru Injector Body (5104-15-1)
2. Slide Compression Spring (9203-2-2) over Injector Plunger (5104-16-1)
3. Screw Plunger Retainer (5104-14-1) onto Injector Plunger (5140-16-1)
4. Install new Injector Seal (5104-13-1) onto Injector Body (5104-15-1
Gun Head Assembly (GMX-2101-01)
Warning: Do not apply grease or oil to Catalyst areas.
1. Place New O-Ring (O-S-012) on Catalyst Fitting (MAX-2019) and Resin Fitting (MAX-
2022). Install both fittings into gun, making sure they are on the correct sides of the
gun block
2. Install new Seal (02441-1) onto Plug (53110-1) then thread Plug into Gun Block
3. Install Flush Valve Assembly (5104-01-01) into resin side of Gun Block
4. Install Diffuser (GMX-2109) into the Mix Housing (GMX-2112)
5. Install new O-Ring (O-S-016) or into Mix Housing (GMX-2112)
6. Insert Catalyst Injector Assembly (5104-03-01) into Diffuser (GMX-2109)
7. Attach Mix Housing (GMX-2112) to Gun Block (GMX-2101-01) using the two (2) Cap
Screws (F-CS-1024-16).
8. Screw Nozzle Adapter (58763-1) onto Mix Housing (GMX-2112)
9. Install new Seal (06286) onto Fluid Cap (06284)
10. Thread Fluid Cap (06284) into Nozzle Adapter (58763-1)
11. Install Air Cap (06285) and Retaining Ring (06291) onto Fluid Cap (06284)
12. Install new O-Ring (O-S-012) into Catalyst Needle Seat area of the Gun Block
