12
TESTING SPRAY PATTERN
1. Testing of your spray pattern should be performed away from original part. Use
paper or cardboard to check the following:
2. Spray pattern width and output
3. Catalyzation
4. Spray pattern definition (fingers and tails):
5.
Adjust as necessary with the “MVP Air Assist” adjustment screw to give the finest
pattern available by eliminating fingers and tails.
6. Check glass distribution
After completion of the above procedures, you may now confidently use your MVP system
