Magnum Venus Plastech Mini Resin Meter User Manual

Page 4

Programming Mini Resin Meter

Programming of the C48 Counter is done through the front panel keypad. English language
prompts, flashing parameter values, and the front panel keypad aid the operator during
programming.
Although the unit has been programmed at Magnum Venus Products. There may be an occasion

where the unit has to be reprogrammed. To enter the programming menu, the

key pressed and

held for two seconds. Once in the programming menu, the

key is used to sequence through the

list of programming parameters. To loop backwards one item in the Programming Menu, press and

hold the

key, then quickly press and hold the

while releasing the

key. Repeatedly

pressing the

key with the

key held will continue the backwards sequencing.

Programming Option Values

The operator can scroll through the available options for a selected parameter by pressing the

keys to enter parameter change mode, and then pressing the

key repeatedly until the

desired option is viewed. The option is entered by pressing the

key, which returns the operator

to the Programming Menu.

Programming Numeric Data Values

The presets, prescaler, and output time values may be accessible when the unit is in the normal
operating mode (not programming mode), providing that the Program Disable input is not activated.

Pressing the

key will sequence the secondary display through the available presets, prescaler,

and output time values.

To change a numeric data value it must be visible on the secondary display. Pressing the

key will allow changing of the value. The two methods for changing numeric data values are "digit
entry" and "auto scrolling".

Digit Entry

If the data entry method has been set to "digit entry", the least significant digit will blink. Pressing

the

key multiple times will select other digits. Pressing the

will increment the selected digit.

The data value will be entered when the

key is pushed, or the old value will be retained if no

key activity is detected for 10 seconds.

Short-Cut - Decrementing Value

To decrement a digit value, press and hold the

key and then press the

key. This will

decrement the selected digit to zero if held.

Saving Program

All parameter values changed in programming mode are saved when exiting. To exit programming

mode, press and hold the

key for two seconds. The display will momentarily display Prog

SAVE while the parameter values are saved in non-volatile memory. The unit then returns to the
indication display that was last viewed.
