A universal BLACKOUT scene (all channels OFF) is
also available. It appears as scene number 00 in the
menus. The blackout scene has a user settable fade
time.
TO RECORD A SCENE
Set the intensity for each channel in the unit to the
desired brightness.
Hold
MENU/NEXT for aprox. 5 seconds to access
the menus. The display will show
dSET
.
Push
MENU/NEXT until the display shows
SYSt
.
Push
SELECT. The display will toggle between
CnFG
and the currently selected control source.
Push
MENU/NEXT until the display toggles
between
ScEn
and the
00
(scene 00).
Use and to change the scene number. Then push
SELECT to record the intensity levels.
The menu will advance to allow you to set the fade
time for that scene. The display will toggle between
FAdE and the current fade time (seconds).
Use and to change the the time. Then push
SELECT to save the setting.
The display will revert to the scene number selection
menu. If you are operating with a DMX console you
can change the channel intensities and record to
another scene. If operating in local mode you will
have to exit from the menus to set the new channel
intensities.
Hold
MENU/NEXT for aprox. 5 seconds to exit
from the menus.
S c E n
0 0
F A d E
0 0
