Specifications
Model
Companion
Flanges
Application
Class*
A3610
3"
1, 16
A3611
3"
1, 3, 14
A3612
3"
1, 16
A3620
3"
3, 4, 14, 15
A3622
3"
2, 14, 15
A3624
3"
2
A4610
4"
1, 14, 16
A4611
4"
1, 3, 14
A4612
4"
1, 14, 16
A4622A
4"
2
A4623
4"
1, 3, 4, 15
A4624
4"
2
V-15 (A-3600 Series)
V-30 (A-4600 Series)
Aluminum with Teflon Seal
Anodized Aluminum with Teflon Seal
Aluminum with Viton Seal
Aluminum with Viton Seal
Aluminum with Teflon Seal
Aluminum with Viton Seal
Aluminum with Viton Seal
Aluminum with Viton Seal
Aluminum with Viton Seal
Aluminum with Viton Seal
Aluminum with Teflon Seal
Aluminum with Viton Seal
Body & Seal Material
Working
Pressure
150 PSI (10.3 BAR)
150 PSI (10.3 BAR)
150 PSI (10.3 BAR)
150 PSI (10.3 BAR)
150 PSI (10.3 BAR)
150 PSI (10.3 BAR)
150 PSI (10.3 BAR)
150 PSI (10.3 BAR)
150 PSI (10.3 BAR)
150 PSI (10.3 BAR)
150 PSI (10.3 BAR)
150 PSI (10.3 BAR)
Model
Companion
Flanges
Application
Class*
A36501
3"
1, 16
A36502
3"
14
A36521
3"
16
A36522
3"
7
A36551
3"
1
A36552
3"
1
A36572
3"
27, 37
A36582
3"
7, 27
A46501
4"
1, 14, 16
A46502
4"
14
A46521
4"
16
A46522
4"
14
A46551
4"
14
A46552
4"
14
Steel with Viton Seal, 300# Flange
Steel with Viton Seal, 300# Flange
VS-3 (A-36500 Series)
VS-4 (A-46500 Series)
Steel with Viton Seal, 275# Flange
Steel with Viton Seal, 275# Flange
Steel with Teflon Seal, 275# Flange
Steel with Viton Seal, 275# Flange
Steel with Viton Seal, 300# Flange
Steel with Viton Seal, 300# Flange
Steel with Viton Seal, 150# FF
Steel with Teflon Seal, 150# FF
Steel with Viton Seal, 275# Flange
Steel with Viton Seal, 275# Flange
Steel with Teflon Seal, 275# Flange
Steel with Teflon Seal, 275# Flange
Body & Seal Material
Working
Pressure
300 PSI (20.7 BAR)
300 PSI (20.7 BAR)
300 PSI (20.7 BAR)
300 PSI (20.7 BAR)
300 PSI (20.7 BAR)
300 PSI (20.7 BAR)
300 PSI (20.7 BAR)
300 PSI (20.7 BAR)
300 PSI (20.7 BAR)
300 PSI (20.7 BAR)
300 PSI (20.7 BAR)
300 PSI (20.7 BAR)
300 PSI (20.7 BAR)
300 PSI (20.7 BAR)
Applications Class Description
Class
Number
Refined petroleum products
1
Aviation and jet fuel
2
Variety of products including: liquid sugars, sweeteners, syrups, & vegetable oils
3
Treated waters & solvents where no red metals are allowed
4
Chlorinated solvents
7
Crude Oil
14
Oil-based & Water-bases latex products, polyester, resins, herbicides, & nitrogen fertilizers
15
General Solvents, 200 proof alcohol
16
Alkaline pH Liquids including: latex products, adhesives, & liquid fertilizers
27
Sodium Hydroxide solutions, high sulfur crude oil, & alkaline pH liquids
37
