Liquid Controls V-15, V-30, VS-3, and VS-4 Valves - Manual (Page 16)

16
Item No. Description Part No.
110 Housing 40731
124 Valve Cap 43985
133 Cup 43529
138 Guide 43953
140 Bearing (2) 09050
260 Inner Bearing (2) 47889
270 Shaft Case Seal (2) 47891
337 Link (2) 43534
338 Link Arm 43533
354 Seal Ring 40736
368 Valve Shaft 40746
370 Guide Shaft 40737
382 Compression Spring 40735
412 Cap Casket 40738
424 Flange Gasket 40871
450 O-Ring (2) 09046
455 O-Ring (2) 09311
465 Upper Seal Ring 40742
541 Cotter Pin (4) 04005
543 Tapered Groove Pin 06822
559 Retaining Ring 04001
564 Retaining Ring (2) 04003
610 Screw, .500-13 x 1.50 (2) 06057
611 Screw, .500-13 x 2.25 (2) 00244
615 Screw, #10-24 x .375 (2) 06819
626 Screw, .500-13 x 1.50 (4) 06057
718 Flat Washer (8) 04685
727 Dashpot Washer 40944
741 Flat Washer (4) 06818
*N/S = Not for Sale
Illustrated Parts Breakdown - V-15 Valves
Model No. A3610 A3611 A3612 A3620 A3622 A3624
Item No.
110 40731 40731 40731 40731 40731 40731
124 43985 43985 43985 43985 43985 43985
133 43529 43998 43529 43529 43529 43529
138 43953 43953 43978 43953 43978 43953
140 09050 09050 09050 09050 09050 09050
260 47889 47889 47889 47889 47889 47889
270 47891 47891 47891 47891 47891 47891
337 43534 43534 43534 43534 43534 43534
338 43533 43533 43533 43533 43533 43533
354 40736 40736 43982 40736 43982 40736
368 40746 40746 40746 40746 40746 40746
370 40737 40737 40737 40737 40737 40737
382 40735 40735 40735 43535 43535 43535
412 40738 46070 40738 46070 40738 40738
424 40871 46069 40871 N/A 40871 40871
450 09046 09046 09047 09046 09047 09046
455 09311 09311 09045 09311 09045 09311
465 40742 40742 07209 40742 07209 40742
541 04005 04005 04005 06936 06936 06936
543 06822 06822 06822 06822 06822 06822
559 04001 N/A 04001 06820 06820 06820
564 04003 04003 04003 06821 06821 06821
572 N/A N/A 07207 N/A 07207 N/A
610 06057 06057 06057 06057 06057 06057
611 00244 00244 00244 00244 00244 00244
615 06819 06819 06819 06819 06819 06819
626 06057 06057 06057 06057 06057 06057
718 04685 04685 04685 04685 04685 04685
727 40944 N/A 43521 43521 43521 43521
741 06818 06818 06818 06818 06818 06818
Part No.
