Step 4 – Attaching the Wall Plate to the Wall

Option A – If the Wall is Drywall

To attach the Wall Plate to drywall, locate the two wooden studs with a Stud Finder
as shown in Figure 8. After you have determined the spot where you believe the
center of each stud to be (using the Stud Finder), hammer a small nail into that spot
far enough to confirm that you are hammering into solid wood (and not something
less dense, like particle board), then remove the nail when done.

Line up the left top hole of the Wall Plate with the stud center marked on the wall at
the desired height. Then, use a pencil to mark the wall through the top left hole in
the Wall Plate over the center of one of the studs as shown in Figure 9.

To attach the Wall Plate to the wall, drill a 3mm pilot hole where the top left pencil
mark was made. Using a Hex Nut Wrench, drive 1 Hex Screw with Washer (Bag 6)
through the one of the top left slots in the Wall Plate and through the drywall into
the stud as shown in Figure 10.

Once the top left screw is secure, adjust the Wall Plate until it is level using the Built-in
Bubble Level/Spirit Level as shown in Figure 11. With a pencil mark the desired location
for the 3 remaining holes in the center of the two studs you identified. Drill the 3
remaining holes with a 3mm drill bit where marked.

Using a Hex Nut Wrench, drive in the additional 3 Hex Screws and Washers (Bag
6) to secure the Wall Plate to the wall as shown in Figure 12. Screw tightly enough
to produce a strong bond, but do not over-tighten or there may be damage to the
mount or screws.

Caution:

Due to the weight of the TV it is essential to mount the Wall Plate

to at least 2 wooden studs and that all 4 screws be used when mounting
the Wall Plate to the wall.

Figure 8

Drywall with Exposed Studs

Stud Finder

Figure 9

Drywall Stud

Figure 10

Drywall Stud

yw

yw

a

Hex Nut
Wrench

Washer

Wa

s

s

Hex

Screw

Figure 11

Built-in Bubble Level/

Spirit Level

Wall Plate

Wall Plate

Figure 12

Hex Nut
Wrench

Drywall Stud

Assembly/Installation

Wall Plate

Wall Plate

her

h

Wall Plate

Wall Plate

Wall Plate

Wall Plate

Washer

r

r

r

er

r

r

Washer

Washer

Hex Screw

rre

w

H

H

w

w

w

w

w

w

w

w

25

25

www.levelmount.com

1-888-229-1459

EU: +0044 844 567 2657

UK: 0844 567 2657

©2011 Level Mount - Patents Pending

Paso 3 – Fijar los Brazos Fijos o Giratorios a la parte trasera
de su televisor

Este paquete incluye tornillos de distintos tamaños que encontrará en las Bolsas 1 a 5.
Por favor, asegúrese de utilizar el tamaño de tornillo adecuado para su televisor.
Los televisores pequeños necesitan las siguientes herramientas: (Para la mayoría de
televisores menores de 50’’ o 127 cm)

Tornillo M4 (Bolsa 1) o Tornillo M5 (Bolsa 2)

Arandelas de presión M4 (Bolsa 1) o arandelas de presión M5 (Bolsa 2)

Arandelas 20 mm x 5.5 mm x 1,0 mm (Bolsa 5)

Es posible que necesite una arandela adicional para evitar que la cabeza del

tornillo se incruste en la parte trasera del televisor

Brazo fijo, giratorio o voladizo

Separador (Bolsa 5) Sólo en caso de que la parte trasera de su televisor sea

hueca.
Los televisores grandes necesitan las siguientes herramientas: (Para la mayoría de
televisores mayores de 50’’ o 127 cm)

Tornillo M6 (Bolsa 3) o Tornillo M8 (Bolsa 4)

Arandelas de presión M6 (Bolsa 3) o arandelas de presión M8 (Bolsa 4)

Brazo fijo, giratorio o voladizo

Separador (Bolsa 5) Sólo en caso de que la parte trasera de su televisor sea

hueca.

Para fijar los brazos fijos o giratorios a la parte trasera de su televisor, coloque los 2
tornillos de cada brazo en los agujeros del brazo fijo o giratorio y apriételos con cuidado
en los agujeros de la parte trasera de su televisor. Si encuentra resistencia, saque de
inmediato el tornillo y escoja otro tamaño que entre fácilmente y permita fijar el tornillo
de manera segura. Apriete bien los tornillos a la parte trasera de su televisor, tal y como
muestran las Imágenes 7.

Cuidado: Apriete los tornillos sólo hasta que estén seguros, con cuidado de no

pasarse de rosca.

Arandelas

19.05mm x 5.3mm x

1.2mm

M4/M5/M6 o
M8 Arandelas
de presión

M4/M5/M6 o
M8 Tornillo

Paso 2c – Fijar los Brazos de Extensión a la parte trasera
del televisor

Los televisores pequeños necesitan las siguientes herramientas: (Para la mayoría de

televisores menores de 50’’ o 127 cm)

• Tornillo M4 (Bolsa 1) o Tornillo M5 (Bolsa 2)
• Arandelas de presión M4 (Bolsa 1) o arandelas de presión M5 (Bolsa 2)
• Arandelas 19.05mm x 5.3mm x 1.2mm (Bolsa 5)
• Es posible que necesite una arandela adicional para evitar que la cabeza del

tornillo se incruste en la parte trasera del televisor

• Brazo de extensión
• Separador (Bolsa 5) Sólo en caso de que la parte trasera de su televisor sea

hueca.

Los televisores grandes necesitan las siguientes herramientas: (Para la mayoría de

televisores mayores de 50’’ o 127 cm)

• Tornillo M6 (Bolsa 3) o Tornillo M8 (Bolsa 4)
• Arandelas de presión M6 (Bolsa 3) o arandelas de presión M8 (Bolsa 4)
• Brazo de extensión
• Separador (Bolsa 5) Sólo en caso de que la parte trasera de su televisor sea

hueca.

Para fijar los Brazos de Extensión a la parte trasera de su televisor, coloque los
2 tornillos de cada brazo en los agujeros del Brazo de Extensión y atorníllelos
con cuidado a la parte trasera de su televisor. Si encuentra resistencia, saque de
inmediato el tornillo y escoja otro tamaño que entre fácilmente y permita fijar el
tornillo de manera segura. Apriete bien los tornillos a la parte trasera de su televisor,
tal y como muestran las Imágenes 5..

Arandelas

19mm x 5.3mm x 1.2mm

Destornillador

Phillips

Brazo de extensión

Separadores

Utilice el separador sólo en caso de que la parte

trasera de su televisor sea hueca

Imagen 4

Montaje/Instalación

Imagen 5

Televisor

Televisor

de pantalla

de pantalla

plana

plana

Brazo de

Brazo de

extensión

extensión

inferior

inferior

Brazo de

Brazo de

extensión

extensión

superior

superior

Brazo fijo

Brazo fijo
o Giratorios

o Giratorios

Imagen 6

Utilice el separador sólo en caso de que la

parte trasera de su televisor sea hueca

Tornillo M4, M5,
M6/M8

Arandelas de presión
M4/M5/M6/M8

Brazo fijo o

giratorio

Separa dores

Separa dores

Destornillador

Phillips

Imagen 7

Televisor

Televisor

de pantalla

de pantalla

plana

plana

Brazo fijo

Brazo fijo
o Giratorios

o Giratorios
