DNT Digital Processor
LECTROSONICS, INC. 10
Mandatory Settings
Dante Controller Software - Network
Settings
Connect the processor to the computer with the Dante
Primary port either directly or through a gigabit switch.
Confirm that the 1G and LINK/ACT LEDs next to the
Dante port are flickering.
Launch the Dante Controller software. A brief splash
screen appears, followed by the Network View/Rout-
ing screen. The serial number of the connected pro-
cessor will appear in the bars labeled Receivers and
Transmitters.
Processor name and
serial number appear in
the blue bars
Double click on either blue
bar to open the Device View
dialogue box
Double click on the processor name/serial number to
open the Device View dialog box. Under the Network
Config tab, select Switched.
Select
Network
Config
Select
Switched
Dante Primary Port
Select the Device Config tab, then set the sample
rate to 48k. The sample rate MUST be 48k so the DSP
(filters, etc.) will operate as they should.
Device Config Tab
Select 48k Sample Rate
Latency can be adjusted under the same tab. The
setting depends upon the number of switches in the
network.
The other tabs in the Device View dialog box are used
to rename channels and check the status of several
parameters.
Consult the
Help menu for details and explanations of
Dante Controller software.
NOTE: Once everything is set up and audio is
flowing to and from the network, a second gigabit
switch and network can be added and the mode
can be changed to Redundant.
