Specifications
SPECIFICATION CHANGES: LEADER ELECTRONICS CORP. reservers the right to discontimue the sale of instruments and/or change the specifications of
instrments at any time without responsibility for the incorporation of new features in the instrumens already sold.
LEADER INSTRUMENTS CORP. (U.S.A.) PHONE:1-714-527-9300
LEADER INSTRUMENTS (H.K.) LTD. PHONE:852-2721-2503
LEADER ELECTRONICS CORP. BEIJING OFFICE PHONE:86-10-8511-8606/8607
LEADER INSTRUMENTS (H.K.) LTD. DONGGUAN OFFICE PHONE:86-769-83829381, 83829391
LEADER ELECTRONICS CORP. SHANGHAI OFFICE PHONE:86-21-62756905, 62759629
LEADER ELECTRONICS EUROPEAN OFFICE PHONE:31-40-2565008
Standards
Supported Standards: ISO/IEC 13818-1
Profile and Level MP@HL, MP@ML, 422@ML, 422P@HL
DVB-ASI I/O
Input Connector
Input Connector: BNC-R
Number of Input Connectors: 1 connector, 75 Ω
Maximum Input Voltage: ±2 V (DC + peak AC)
Input Signal
Serial Clock: 270 MHz
Transmission Mode: Packet/Burst
Maximum Bit Rate: 66 Mbps
Supported Packet Sizes: 188, 204, and 208 bytes
Packet Size Detection: Audio Detects supported packet sizes
Decoding Function
Video Formats: 1920x1080i / 59.94, 60, 50 (4:2:0,4:2:2)
1280x720p / 59.94, 60, 50 (4:2:0,4:2:2)
720x480i / 59.94 (4:2:0,4:2:2)
720x576i / 50 (4:2:0,4:2:2)
Audio Signals: MPEG-2 AAC, Dolby Digital(AC-3),
LPCM(SMPTE 302M)
(LV 58SER40
A (DIGITAL AUDIO) is
necessary separately. In addition, when
decoding Dolby Digital (AC-3), Dolby E option
is necessary)
* This unit decodes only one set of video data and audio data.
Even if you use the LV 5800 multi display, the unit cannot decode different
video and audio streams simultaneously.
If you assign the display showing the data that this unit is decoding to
multiple displays and you change the PID of the data being decoded, the
PIDs on all displays change simultaneously.
Video Signal Waveform Display Function
Waveform Operation
Display Mode: Overlay display (displays component signals
overlaid)
Parade display (displays component signals
side by side)
Y, C
B
, C
R
to G, B, R Conversion: Converts Y, C
B
, C
R
signals into G, B, R and
displays the result
Pseudo-Composite Display: Displays component signals artificially as
composite signals
Channel Assignment: G, B, R or R, G, B order (when displaying G,
B, R converted signals)
Line Select: Displays the selected line
Image Quality Adjustment: Adjusts the brightness
Vertical Axis
Sensitivity
V Scale: 0 to 0.7 V, -0.3 to 0.7 V
% Scale: 0 to 100 %, -50 to 100 %
Gain: x1, x5, variable
Variable Gain: x0.2 to x2
Amplitude Accuracy: ±0.5 %
HDTV Frequency Characteristics
Y Signal: ±0.5 % (1 to 30 MHz)
C
B
,C
R
signal: ±0.5 % (0.5 to 15 MHz)
Low-pass Attenuation: 20 dB or more (at 20 MHz)
SDTV Frequency Characteristics
Y Signal: ±0.5 % (1 to 5.75 MHz)
C B ,C R signal: ±0.5 % (0.5 to 2.75 MHz)
Low-pass Attenuation: 20 dB or more (at 3.8 MHz)
Horizontal Axis
Line Display
Display Mode: Overlay: 1H, 2H
Parade: 1H, 2H, 3H
Magnification: x1, x10, x20, ACTIVE, BLANK
Field Display
Display Mode: Overlay: 1V, 2V *1
Parade: 1V, 2V, 3V
Magnification: x1, x20, x40
Time Accuracy: ±0.5 %
Cursor Measurement
Composition
Horizontal Cursors: 2 cursors (REF and DELTA)
Vertical Cursors: 2 cursors (REF and DELTA)
Amplitude Measurement: Percentage and voltage displays
Time Measurement:
Displays time in seconds
Frequency Measurement: Displays the frequency by considering the
time between cursors to be a cycle
*1 The 2V display is not allowed if the input signal is progressive.
Vectorscope Display
Scale: 75 %, 100 % (for the color bars)
Gain: x1, x5, IQ-MAG, variable
Variable Gain: x0.2 to x2
Amplitude Accuracy: ±0.5 %
IQ Axis: Show or hide
Pseudo-Composite Display: Displays component signals by converting to
composite signals that have burst added
artificially.
(The color matrix for HDTV signals is
converted to SDTV.)
Image Quality Adjustment: Adjusts the brightness
Picture Display:
HDTV Display: Displayed by sampling pixels
SDTV Display: Displayed by interpolating pixels
Marker Display: Center marker display
4:3 or 16:9 marker display
Safe action marker display
Safe title marker display
Line Select: Marks the selected line
Display Size: Optimized display, actual size display
Image Quality Adjustment: GBR level adjustment, contrast adjustment,
brightness adjustment
Section and PCR Information
PAT
PAT Detection: Automatically recognizes packets whose PID
is 0000h as PAT
Cycle Measurement *2: Measures the PAT cycle in 1-ms intervals
PAT data display: PAT dump display
PMT
PMT Detection: Select the PID of the PMT to be decoded
Cycle Measurement *2: Measures the PMT cycle in 1-ms intervals
PMT data display: PMT dump display
NIT
NIT Detection: Automatically detects packets with the NIT
PID specified by the PAT.
Cycle Measurement *2: Measures the NIT cycle in 1-ms intervals
CAT
CAT Detection: Recognizes packets whose PID is 0001h as CAT
Cycle Measurement *2: Measures the CAT cycle in 1-ms intervals
PCR
PCR detection: Automatically detects packets with the PCR
PID specified by the selected PMT
Cycle Measurement *2: Measures the PCR cycle in 1-ms intervals
PCR jitter: Measures the PCR accuracy based on the
internal reference clock
*2: If a section is divided into multiple TS packets, the cycle is measured for each section.
Dump Display
Function: Dump display of the PAT, PMT, and the dump
display of the selected packet
Notation: Displays binary and hexadecimal values and
contents
Bit Rate Display
Function: Displays the bit rate and cycle of the main
sections and packets
Bar Display: Displays the occupied bandwidth with respect
to the TS bit rate using bars
Displayed Sections: NIT, CAT, PAT, and PMT
Displayed Packets: Video, audio, PCR, and null
General Specifications
Environmental Conditions: Conforms to the LV 5800
Power Supply: Supplied from the LV 5800
70 W max. (if one unit is installed to the LV 5800)
20 W max. (additional power consumption for
each additional unit installed to the LV 5800)
Weight: 0.4 kg
Accessory: Instruction manual ...................................... 1
