Impulse GOT5100T-832 User Manual
Page 2
446
* All specifications and photos are subject to change without notice.
axiomtek.com
Overview
Industrial Panel
Computers &
Monitors
Heavy-duty Fanless
Touch Panel
Computers
Digital
Signage
Solutions
Healthcare
& Medical
Solutions
Open Frame
Panel
Computers
Accessories
© 2013 Axiomtek Co., Ltd. All rights reserved.
Ordering Information
Specifications
Optional EOS Installation
Optional OS Installation
Dimensions
GOT5100T-832
10.4" SVGA Intel
®
Atom™ N2600 fanless touch panel
computer with terminal block connector
GOT5100T-832-J
10.4" SVGA Intel
®
Atom™ N2600 fanless touch panel
computer with screw type connector & AC-DC 60W power
adapter
E225840102
Desktop stand
Wireless kit
802.11 b/g wireless LAN kit
* Specification and certifications are based on options and may vary.
Windows
®
Embedded 7 (32-bit)
Windows
®
7 (32-bit)
I/O Connector
1 x RS-232/422/485 (COM 1)
1 x RS-232 (COM 2)
2 x 10/100/1000Mbps Ethernet
4 x USB 2.0
1 x Audio (Line-out)
Expansion Interface
1 x PCIe Mini Card
Touchscreen
Resistive type
Power Supply
10~30VDC
100~240VAC, 60W power adapter
Dimension
292.5 mm (11.52") (W) x 45.8 mm (1.80") (D)
x 235.8 mm (9.28") (H)
Packing Dimensions
415 mm (16.34") (W) x 100 mm (3.94") (D)
x 315 mm (12.4") (H)
Weight (net/gross)
1.8 kg (3.96 lb)/3 kg (6.61 lb)
Environment
Operating temperature:
0° ~ +50°C (32°F ~ 122°F)
(with W.T. DRAM/HDD in airflow condition)
0° ~ +45°C (32°F ~ 113°F) (with W.T. DRAM/HDD)
Storage Temperature:
-30°C ~ +80°C (-22°F ~ +176°F)
Relative humidity:
10% ~ 95% @ 40°C; non-condensing
Operation vibration:
2G, 5~500Hz, random for CompactFlash™
Certification
CE
AC power adapter
(for GOT-5100T-832)
