Features, Atom™ processor n2600

background image

* All specifications and photos are subject to change without notice.

445

1. Power switch

2. Terminal block for DC power input

or 3. Screw conn. w/ AC power adapter

4. USB x 2

5. COM 1 (RS-232/422/485)

6. COM 2 (RS-232)

7. Ethernet x 2

8. USB 2.0 x 2

9. Audio (Line-out)

GOT5100T-832

10.4" SVGA TFT Fanless Touch Panel

Computer with Intel

®

Atom™ Processor

N2600

10.4" SVGA (800 x 600) color TFT LCD display

Fanless design with Intel

®

Atom™ processor N2600 1.6 GHz

Supports WLAN module & internal antenna.

Supports 2 Giga LAN, 4 USB 2.0 & 4 COM ports

Supports panel mount, wall mount, VESA arm,

desktop stand (optional)

Plastic and IP65-rated front bezel

Supports RFID (optional)

Introduction

Specifications

The GOT5100T-832 is a 10.4" Intel

®

Atom™-based fanless touch panel computer. In

response to market demand, this panel computer is a cost effective solution. It adopts a

modern, super sleek and fanless design and is equipped with a 10.4" TFT LCD as well as

Intel

®

Atom™ processor N2600 1.6 GHz. For wireless network connection, the GOT5100T-

832 offers a mini card slot. By just plugging in the mini card WLAN card, customers can

have instant access to wireless LAN/GPRS/ GSM/3G environments. Besides, it provides

two types of power input. One is DC power input (10~30VDC) with terminal block

connector. The other is AC power adapter with screw type connector.

Super slim & ultra light design

The GOT5100T-832 is a super slim touch panel computer for space-limited environment

with its thickness of 45.8mm and weight of 1.8 kg only, which make it installed

everywhere.

Built-in internal WLAN antenna

The GOT5100T-832 provides a mini card slot and a built-in WLAN antenna for wireless

network connections. By simply plugging in the wireless LAN card, customers can use the

GOT5100T-832 in a wireless LAN/GPRS/GSM /3G environments.

Excellent thermal solution: aluminum back chassis

With Axiomtek's patent for plastic plus aluminum mechanism design, the GOT5100T-832

can dissipate the heat easily and keep the system operation stable

Features

Side view

Desktop stand

Fanless

Low Power

DualView

1

2

3

5

6

7

8 9

4

Front Bezel

IP65, NEMA 4 rugged protection, plastic front bezel

LCD Panel

Display Type

10.4" SVGA TFT LCD

Brightness (cd/m

2

)

400 nits

Resolution

800 x 600

Viewing Angel (H/V) 140°/120°

Main System

CPU

Intel

®

Atom™ processor N2600

1.6 GHz

Chipset

Intel

®

NM10 Express

System Memory

1 x 204-pin DDR3 SO-DIMM

up to 2 GB

BIOS

AMI UEFI BIOS

Storage

1 x 2.5" SATA HDD

1 x CompactFlash™

Watchdog Timer

255 levels, 0~255 sec.

Onboard Graphics

Integrated in Intel

®

GFX

DDR3

DDR3

DDR3
