Controlled Products Systems Group SPX-7400 User Manual

Page 2

This manual covers the operation and setup of the Cypress Suprex® Fiber Optic SPX-7400 series units.

Overview:

The SPX-7400 series of Fiber Optic solutions provides a bridge from Card Readers with gates or door hardware to most
access control manufacturers panels. The SPX or Suprex® products include both the remote ( Door/Gate ) unit and the
central ( AC Panel ) unit.

Features:

-- Available in single mode or multi-mode
-- Includes complete solution with remote ( reader/gate/door ) and central ( panel ) interface.
-- Service mode for setup and configuration of Expansion modules.
-- Field configurable reader formats
-- Multifunction indicator for determining operational status of the unit
-- Auxiliary I/O connections available for Door/Gate/Panel status signaling.
-- Multiplexing of RF bridge providing for additional door/gate on a single Fiber link.
-- Economical expansion capabilities using Suprex® Lynk technology

Fiber Optic Specifications:

Module connections utilize standard "ST" style connections

NOTE: Single Mode or Multi Mode must be Specified at time of order.

SPX-7400 Multimode: Loss Budget 13 dB 850 nm"

62.5/125 Fiber

Loss Budget 9 dB 850 nm"

50.0/125 Fiber" "

SPX-7410 Single mode: Loss Budget 20 dB 1300 nm" 9/125 Fiber

Physical

SPX-7400 - Aluminum Enclosure
4.45” x 3.08” x 2.0” ( Each Unit )

Temp

Storage(-55˚C to + 150˚C)
Operating(-40˚C to +80˚C)

Humidity

95% (non-condensing)

Power

Input

Unreg Input 8 to 16 VDC* @ 300mA Max

Power

Output

+5VDC @100mA

Data I/O

Interface

Reader -Wiegand, Strobed (Clock & Data), F/2F
LED - 0 - 30V

Relays

Max Switching

(220Vdc 30W (resistive) 1A)

Relays

Max Switching

(250Vac 37.5VA 1A)

Relays

Running Spec with load

(30Vdc 1A (resistive), 1 x 10

operations at 20

Relays

Running Spec with load

125Vac .3A (resistive), 1 x 10

operations at 20

Electrical and Mechanical Specifications

Suprex® SPX-7400 Series

Cypress Computer Systems, Inc.

⌖ Lapeer, MI 48446 ⌖
